This type of slot wedge is a class B or class F insulating material, which is widely used in various types of motor stator insulation.
This product has excellent mechanical strength and excellent electrical properties,
Material used: 6021 polyester film , DMD B or DMD F
Material thickness: can be customized according to the actual needs of customers
Application: High Voltage Insulation
Color: white, pink
Length: 1000mm
Size: produced according to customer needs
|
Properties |
UNIT |
VALUE |
|
|
Tensile strength(MD and TD) |
25μm~100μm |
MPA |
more than 150 |
|
Elongation at break (MD and TD) |
25μm~50μm |
% |
more than 60 |
|
Shrinkage (MD and TD) |
25~190μm |
% |
less than 3.0 |
|
Volume resistivity |
|
|
more than 1.0×1014 |
|
Relative dielectric constant (50Hz) |
|
Ω·M |
2.9~3.4 |
|
Dielectric dissipation factor (50Hz) |
|
|
less than 5.0×103 |
|
Density |
kg/m3 |
|
1400+1020 |
|
Surface resistivity |
|
Ω |
more than 1.0×1013 |
|
Melting point |
|
℃ |
more than 256 |
